| KEY | IMAGE | DESCRIPTION | MANUFACTURER'S PART NUMBER | Quantity Required |
|---|---|---|---|---|
| 1 |  | HEAD LAMP ASSEMBLY (White) | 434-84130-60-36 | 1 |
| 2 |  | GROMMET | 150-84153-00 | 1 |
| 3 | | HEAD LAMP UNIT ASSEMLBY | 525-84110-60 | 1 |
| 4 | | HEAD LAMP RIM | 493-84115-60 | 1 |
| 5 |  | LENS ASSEMBLY | 525-84120-60 | 1 |
| 6 |  | SPRING, REFLECTOR SET | 195-84324-00 | 3 |
| 7 |  | HEAD LAMP BULB (6V-25/25W) | 251-84114-00 | 1 |
| 8 |  | SOCKET ASSEMBLY | 434-84140-60 | 1 |
| 9 |  | RIM FITTING SCREW | 195-84325-00 | 1 |
| 10 |  | PILOT LAMP ASSEMBLY | 214-84101-61 | 1 |
| 11 |  | PILOT LAMP BODY | 256-84357-61 | 1 |
| 12 |  | PILOT LAMP BULB (6V-1.5W) | 104-83517-10 | 1 |
| 13 | | SOCKET CORD ASSEMBLY | 214-84150-61 | 1 |
| 14 | | BOLT | 97303-08020 | 2 |
| 15 |  | SPRING WASHER | 92901-08100 | 2 |
| 16 |  | NUT | 95301-08600 | 2 |
